Learnings from Contributing to the Rust Project

Learnings from Contributing to the Rust Project

| 9 min read

#rust , #oss , #compiler

I’ve been reading about stages of Rust compilation, and wrote about some of my learnings in a previous post. As I started reading more, I realized that it might be helpful to find a way to contribute to the project, learn more about the compiler and validate my assumptions / understanding of the compiler.

Finding an issue to work on

The rustc compiler is a large codebase, and definitely intimidating at first glance. As with contributing to any new OSS project, I started by looking at the issues that were tagged as beginner friendly and found an issue that was tagged as E-mentor and E-easy: #129599.

It involved adding a new std_features flag to the bootstrap phase of the compiler, that helps in enabling std features for compiler development. This could be features like enabling panic-unwind or backtrace features when building the compiler.

This felt like a good issue to start with, and it was relatively straightforward to understand the issue, but I had to understand how the compiler was bootstrapped and how the std_features flag was passed to the compiler.

I also connected with Onur Ozkan who was the mentor for the issue on zulip chat, and he was very helpful and welcoming throughout the process. Thanks Onur!

What’s bootstrapping?

Bootstrapping is how the compiler compiles itself, typically by using an older version to build a newer version. For rust to bootstrap, it has 4 stages:

Rust Bootstrap Stages
  • Stage 0: Pre-compiled Compiler - the current beta rustc and is downloaded from the internet.
  • Stage 1: Compiler built with the pre-compiled compiler from Stage 0
  • Stage 2: Rebuilding the stage 1 compiler with itself, and this is what get’s distributed with rustup.
  • Stage 3 (optional): We can build libs with this compiler to sanity check that the compiler result is the same as the stage 2 compiler.

The Rustc Dev Guide on Bootstrapping has a lot more details on bootstrapping, if you’re interested in learning more.

Getting started

I followed the steps in the Quick Start guide on my macOS machine, and I ran into my first issue:

The ./x.py setup command failed with the following error:

Terminal window
~/Repositories/rust master
./x setup
downloading https://static.rust-lang.org/dist/2024-07-26/rust-std-beta-aarch64-apple-darwin.tar.xz
############################################################ 100.0%
downloading https://static.rust-lang.org/dist/2024-07-26/rustc-beta-aarch64-apple-darwin.tar.xz
############################################################ 100.0%
downloading https://static.rust-lang.org/dist/2024-07-26/cargo-beta-aarch64-apple-darwin.tar.xz
############################################################ 100.0%
extracting /Users/shrirambalaji/Repositories/rust/build/cache/2024-07-26/rustc-beta-aarch64-apple-darwin.tar.xz
extracting /Users/shrirambalaji/Repositories/rust/build/cache/2024-07-26/rust-std-beta-aarch64-apple-darwin.tar.xz
extracting /Users/shrirambalaji/Repositories/rust/build/cache/2024-07-26/cargo-beta-aarch64-apple-darwin.tar.xz
Building bootstrap
   Compiling libc v0.2.157
   Compiling proc-macro2 v1.0.86
   Compiling unicode-ident v1.0.12
   Compiling typenum v1.17.0
   Compiling version_check v0.9.5
   Compiling memchr v2.7.4
   Compiling crossbeam-utils v0.8.20
   Compiling serde v1.0.208
   Compiling rustix v0.38.34
   Compiling cc v1.0.97
error: failed to run custom build command for `serde v1.0.208`


Caused by:
  process didn't exit successfully: `/Users/shrirambalaji/Repositories/rust/build/bootstrap/debug/build/serde-19a5005084e51914/build-script-build` (signal: 9, SIGKILL: kill)
warning: build failed, waiting for other jobs to finish...
error: failed to run custom build command for `crossbeam-utils v0.8.20`


Caused by:
  process didn't exit successfully: `/Users/shrirambalaji/Repositories/rust/build/bootstrap/debug/build/crossbeam-utils-b20f738aa3e877a6/build-script-build` (signal: 9, SIGKILL: kill)
failed to run: /Users/shrirambalaji/Repositories/rust/build/aarch64-apple-darwin/stage0/bin/cargo build --manifest-path /Users/shrirambalaji/Repositories/rust/src/bootstrap/Cargo.toml
Build completed unsuccessfully in 0:00:13

It looked like the build failed because the dependencies couldn’t be compiled. Initially, I thought that I had some system dependencies missing, but later found out that it was because of conflicting system dependencies. I had binutils installed via brew and I had strip in my path, which was conflicting with the strip that was being used by the compiler.

So I had to remove binutils from my path, and then the build was successful:

Terminal window
brew uninstall binutils

What’s that python script doing in my rust compiler?

Wait a minute - why’s there a python script to build the compiler? 🤔

x.py is a wrapper script that calls into the bootstrap tool - a cross-platform build tool backed by cargo, used specifically for the rust project. x.py by itself doesn’t do a lot more, other than checking for the python version and subsequently invoking the bootstrap.py script, which does the following:

  • Parses the CLI arguments and passes it on the bootstrap tool
  • Downloads the rust toolchain, and makes sure that the necessary build tools rustc, cargo etc., are available.
  • Runs the bootstrap build using cargo to compile the bootstrap tool in src/bootstrap. The CLI arguments from earlier are passed to the bootstrap tool.
  • Finally, the bootstrap tool is run with the CLI arguments.

So when we call ./x <subcommand>, it’s actually invoking the bootstrap CLI with the subcommand.

Setting up Zed for Compiler Development

I’ve started using Zed for all of my personal work and I’ve been liking it a lot.

./x setup has an option to add settings to configure VSCode, but not for Zed. This is important for rust_analyzer to work correctly during compiler development. The configuration for rust_analyzer is not very different from VSCode, but needs to be added in a .zed/settings.json in the root of the repo:

.zed/settings.json
{
  "lsp": {
    "rust-analyzer": {
      "initialization_options": {
        "check": {
          "invocationLocation": "root",
          "invocationStrategy": "once",
          "overrideCommand": ["python3", "x.py", "check", "--json-output"]
        },
        "linkedProjects": [
          "Cargo.toml",
          "src/tools/x/Cargo.toml",
          "src/bootstrap/Cargo.toml",
          "src/tools/rust-analyzer/Cargo.toml",
          "compiler/rustc_codegen_cranelift/Cargo.toml",
          "compiler/rustc_codegen_gcc/Cargo.toml"
        ],
        "rustfmt": {
          "overrideCommand": ["./build/host/rustfmt/bin/rustfmt", "--edition=2021"]
        },
        "procMacro": {
          "enable": true,
          "server": "./build/host/stage0/libexec/rust-analyzer-proc-macro-srv"
        },
        "cargo": {
          "buildScripts": {
            "enable": true,
            "invocationLocation": "root",
            "invocationStrategy": "once",
            "overrideCommand": ["python3", "x.py", "check", "--json-output"]
          },
          "sysrootSrc": "./library",
          "extraEnv": {
            "RUSTC_BOOTSTRAP": "1"
          }
        }
      }
    }
  }
}

Making the change

The change involved a couple of steps:

  • Adding a new field std_features in the config.toml file
  • Parsing (deduplicated) and updating the internal rust features config to be passed on the compiler bootstrap process
  • Unit tests
config.toml
[rust]
# other options for compiling rust . . .
std-features = ["panic_unwind"]

How does bootstrap read the config.toml file?

Bootstrap uses toml-rs to parse the config.toml. Also since configuration can be overridden from both the toml file and from command line arguments, the TomlConfig struct implements a Merge trait:

/// Denotes how the config needs to be merged, specifically when handling duplicates.
enum ReplaceOpt {
    /// Silently ignore a duplicated value
    IgnoreDuplicate,
    /// Override the current value, even if it's `Some`
    Override,
    /// Exit with an error on duplicate values
    ErrorOnDuplicate,
}


impl Merge for TomlConfig {
    fn merge(
        &mut self,
    // other options from `TomlConfig` are also required here
        TomlConfig { rust }: Self,
        replace: ReplaceOpt,
    ) {
        fn do_merge<T: Merge>(x: &mut Option<T>, y: Option<T>, replace: ReplaceOpt) {
            if let Some(new) = y {
                if let Some(original) = x {
                    original.merge(new, replace);
                } else {
                    *x = Some(new);
                }
            }
        }
        do_merge(&mut self.rust, rust, replace);
    // merge other fields in `TomlConfig` . . .
    }
}

The config fields are not directly decoded, but decoded into separate sections represented by their own struct. In my case, I only needed to add a field in the Rust struct, corresponding to the [rust] section in the config.toml here.

Deduplicating std_features

Although the previous step handled merging, since we are dealing with a list of values there needed to be some way to deduplicate it, because the internal features representation needs to be based on that.

I reached for the handy HashSet collection, but from the review I understood that the order of std_features could be important, and the current implementation works with this assumption. HashSet does not have deterministic ordering and so I cannot use it, this is because it’s backed by a hashtable and needs to be compute the hashcode for every element and then puts it in a “bucket”. The bucket has no connection to the insertion order, so there’s no way to keep track of the insertion order.

So I implemented it with a BTreeSet instead as suggested in the initial review.

Error Handling in CI Builds

The toml parser handles parsing errors by default, so I didn’t have to do anything there. Since the std_features option can fundamentally change the output of the compiler, we need to throw an error if this config gets passed in CI builds. I really liked the err macro that they had setup for making this easy.

macro_rules! err {
  ($current:expr, $expected:expr) => {
      if let Some(current) = &$current {
          if Some(current) != $expected.as_ref() {
              return Err(format!(
                  "ERROR: Setting `llvm.{}` is incompatible with `llvm.download-ci-llvm`. \
                  Current value: {:?}, Expected value(s): {}{:?}",
                  stringify!($expected).replace("_", "-"),
                  $current,
                  if $expected.is_some() { "None/" } else { "" },
                  $expected,
              ));
          };
      };
  };
}

I usually stay away from macros (skill issue tbh), but I liked this one. I’m still contemplating if this could have been a function, but I digress.

Merging the change - Squashing commits

I addressed all the feedback comments, and the PR was ready for merge. The rust project follows a rebase + squash workflow for contributors. I have had my own reservations about rebase in the past:

I learnt that most of my pain with rebase was probably due to not knowing about rerere which solved a lot of issues dealing with rebase merge conflicts.

However, squashing was new to me and the first time around I botched the squash and messed up the branch. Since it was also a rebase and I pushed upstream, there was no way to undo it (maybe there’s a way, but I gave up pretty quickly).

So I made a new branch, rebased upstream onto it and cherry-picked my changes from the previous changes, and then squashed all of them into a single commit after following through this article.

Finally, after a couple of weeks of picking up my first issue, I got my first PR merged - https://github.com/rust-lang/rust/pull/131315. This might all sound trivial, but hey - I would not have imagined me being able to contribute to the rust project a couple of years ago, it’s good to count the small wins! https://thanks.rust-lang.org/rust/1.83.0/ now lists me as a contributor 😄

Contributor's Screenshot

Looking forward to contributing, learning and sharing a lot more about rustc.

See you in the next one 👋
